TS-231P3-2G (Legacy)
CPU AnnapurnaLabs, an Amazon company Alpine AL314, 4-core, 1.7GHz
CPU Architecture 32-bit ARM
Floating Point Unit yes
Encryption Engine yes
System Memory 2GB SODIMM DDR3
Maximum Memory 8GB DDR3
Memory Slot 1 x SODIMM DDR3
Flash Memory 512 MB (Dual boot OS protection)
Drive Bay 2 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable yes
SSD Cache Acceleration Support yse
Gigabit Ethernet Port (RJ45) 1
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 1(2.5G/1G/100M)
Wake on LAN (WOL) yes
Only the 1GbE port
Jumbo Frame yes
USB 3.2 Gen 1 port 3
Form Factor Tower
LED Indicators Power, Status, LAN, USB, HDD1-2
Buttons Power, Reset, USB Auto Copy
Dimensions (HxWxD) 165 × 102 × 220.6 mm
Weight (Net) 1.46 kg
Weight (Gross) 2.46 kg
Operating Temperature 0 – 40 °C (32°F – 104°F)
Storage Temperature -20 – 70°C (-4°F – 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 60W/65W
adapter (12VDC), 100-240VAC
Power Consumption: HDD Sleep Mode 8.46 W
Power Consumption: Operating Mode, Typical 15.6 W
Tested with drives fully populated.
Fan 1 x70mm, 12VDC
System Warning Buzzer
Kensington Security Slot yes
Standard Warranty 2
